› 14.4V, 420Wh/29.4Ah large capacity
› 250W/20A constant load, 305W peak load
› 100W/6A fast charging support
› 2x D-tap power sockets, 150W load
› 5-LED digital power indicators
› SONY/RED viewfinder power info display
› Multiple circuit protections
ONE BATTERY, ONE DAY
PB-C420S reaches the world’s largest capacity:
420Wh of handheld V-mount battery, long time
power supply for cameras, monitors, lights and
many power hungry devices of broadcast and
film industry.
14.4V, 420Wh, 2x D-tap
PB-C420S consists of 24pcs Li-ion cells, 14.4V nominal
voltage, 420Wh, 29.4Ah large capacity, and provides
with 2x D-tap sockets at left and right side, for
camera-top devices.
250W Constant High Load
PB-C420S outputs at least 250W/20A high load even
at 1% capacity (Peak load up to 305W), to drive high
power Cine cameras and on-camera devices together.
The high load cells will also ensure battery life
comparing to normal load batteries if long time full
load output. Over current protection: 24A.
100W 6A Fast Charging
PB-C420S supports 100W/6A fast charging
to save more than 50% charging time. The
420Wh battery can be charged from 0 to 80%
after 3.9 hours, and fully charged within 5.3
hours.
Reliable SWIT Quality
The PB-C420S internal controller supports
multiple protection circuit, to detect any
abnormal conditions includes over load, over
charging, over discharging, high temperature,
short circuit, etc, and actively protect the
devices from potential safely issue. SWIT
battery will always be your reliable choice.
Nominal Voltage | 14.4V |
Capacity | 420Wh/29.4Ah |
Power Load | 250W / 20A constant, 305W peak |
Charging | DC 16.8V, 6A |
D-tap | 2x D-tap 150W/10A in total |
Mount Type | V-mount |
Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C (Capacity and Max Load may decrease when operating below 0°) |
Net weight | Net 2.07kg; With package2.15kg |
Dimensions | 155×101×80mm |
